Case Study of Mixing AC and DC Charging

Installing both AC and DC charging stations in one station can greatly benefit electric vehicle (EV) owners.
Dual Charging Options:
This EV station both AC Level 2 chargers with 7KW,22KW output power, and DC fast chargers capable of providing a robust 120kW charge. This dual setup empowers EV owners with the flexibility to choose the charging method that best aligns with their vehicle's needs and their schedule.

AC chargers, which utilize alternating currents, are ideal solutions for workplaces, public parking lots, and private garages, and provide a slower charging rate than their DC counterparts. However, their ubiquity makes them ideal for topping off a car's battery while it is parked for an extended period.

DC chargers, which utilize direct currents, offer much faster charging speeds, but are far less common and found mainly in commercial charging stations or along highways. Their high power output makes them ideal for quick, on-the-go charging sessions, allowing EV owners to top off their battery in a much shorter time.
